If you want elegant styling and exceptional performance, check out the Limelight® Collection. You’ll learn what makes these spas special, including unique massage, spacious interiors and a range of models that fit from four to seven adults.

Plus, you can count on legendary Hot Spring quality, Energy Smart® features and innovative water care options, like the FreshWater® Salt System that helps you spend less time caring for your spa, and more time enjoying it.

STUNNING LIGHTS MEET POWERFUL JETS

The largest spa in the Hot Spring® Limelight® Collection, Prism seats seven adults and features a relaxing lounge, plus an Adirondack-style seat with wrist, calf and foot therapy jets. The footwell includes a powerful, extra-large jet for enhanced foot and leg massage, along with several precision directional jets in corner and side seats.

Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider

(Actual colors and product may differ from on screen representation. Please see your local dealer to verify.)

Cabinet

Shell

PRODUCT SPECS

Seating Capacity
7 Adults
Dimensions
7’7” x 9’2” x 38” 2.31m x 2.79m x 0.97m
Jet Count
73
Lighting System (interior)
Raio® multi-color interior points of light (38)
Exterior multi-color lighting with timer
Water Care System
FreshWater® Salt System Ready
Vinyl Cover Colors
Caramel
Chestnut
Slate
Jet Pump 1
Wavemaster® 9200
Two-speed
2.5 HP Continuous Duty
5.2 HP Breakdown Torque
Jet Pump 3
Wavemaster® 9000
One-speed
2.5 HP Continuous Duty
5.2 HP Breakdown Torque
Circulation Pump
SilentFlo 5000® for quiet continuous filtration
Control System
IQ 2020® with LCD control panel
230v/50amp, 60Hz
230v/70amp, 60Hz (optional)
Includes G.F.C.I. protected sub-panel
Cover Lifters (Optional)
CoverCradle® included
Energy Efficiency
FiberCor® insulation; Certified to the APSP 14 National Standard and the California Energy Commission (CEC) in accordance with California law
Water Capacity
525 gallons/1,990 liters
Weight
1,190 lbs./540 kg dry
6,795 lbs./3,085 kg filled*
Heater
No-Fault®, 4000w/230v
Entertainment systems (optional)
Wireless Entertainment
Water Features
Vidro® backlit ribbon waterfall
Jet Pump 2
Wavemaster® 9000
One-speed
2.5 HP Continuous Duty
5.2 HP Breakdown Torque
Effective Filtration Area
150 sq. ft., top-loading filters
Steps (Optional)
Everwood®
Polymer
Vinyl Cover
3.5" to 2.5" tapered
2 lb. density foam core with hinge seal
Hot Tub Jets
1 JetStream® XL
1 XL Dual Rotary Jet
2 XL Single Rotary Jets
3 XL Directional Jets
7 Standard Dual Rotary Jets
4 Standard Single Rotary Jets
4 Standard Directional Jets
10 Rotary Precision® Jets
41 Directional Precision® Jets

RELAX AND CONNECT

The roomy interior seats up to seven adults in a spa that fits comfortably on most patios. It includes a jetted foot pod with seven precision directional jets for a penetrating foot massage from every seat.

Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider

(Actual colors and product may differ from on screen representation. Please see your local dealer to verify.)

Cabinet

Shell

PRODUCT SPECS

Seating Capacity
7 Adults
Dimensions
7’5” x 7’5” x 38” 2.26m x 2.26m x .97m
Jet Count
49
Lighting System (interior)
Raio® multi-color points of light (32)
Exterior multi-color lighting with timer
Water Care System
FreshWater® Salt System Ready
Vinyl Cover Colors
Chestnut
Caramel
Slate
Jet Pump 1
Wavemaster® 9200
Two-speed
2.5 HP Continuous Duty
5.2 HP Breakdown Torque
Circulation Pump
SilentFlo 5000® for quiet continuous filtration
Control System
IQ 2020® with LCD control panel
230v/50amp, 60Hz
Includes G.F.C.I. protected sub-panel
Cover Lifters (Optional)
CoverCradle II®, CoverCradle®, Lift ‘n Glide®, UpRite®
Energy Efficiency
FiberCor® insulation; Certified to the APSP 14 National Standard and the California
Energy Commission (CEC) in accordance with California law
Water Capacity
445 gallons/1,685 liters
Weight
1,015 lbs./460 kg dry
5,950 lbs./2,700 kg filled*
Heater
No-Fault®, 4000w/230v
Entertainment systems (optional)
Wireless Entertainment
Water Features
Vidro® backlit ribbon waterfall
Jet Pump 2
Wavemaster® 9000
One-speed
2.5 HP Continuous Duty
5.2 HP Breakdown Torque
Effective Filtration Area
100 sq. ft., top loading filters
Steps (Optional)
Everwood®
Polymer
Vinyl Cover
3.5" to 2.5" tapered
2 lb. density foam core with hinge seal
Hot Tub Jets
1 XL Dual Rotary Jet
1 XL Single Rotary Jet
2 XL Directional Jets
4 Standard Single Rotary Jets
2 Standard Directional Jets
4 Rotary Precision® Jets
35 Directional Precision® Jets

A REJUVENATING EXPERIENCE

The open-seat design creates a spacious interior that accommodates up to seven people in this spa with a conservative 7’ x 7’ footprint. A pod in the footwell houses four precision directional jets for a foot massage in nearly every seat.

Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider

(Actual colors and product may differ from on screen representation. Please see your local dealer to verify.)

Cabinet

Shell

PRODUCT SPECS

Seating Capacity
7 Adults
Dimensions
7’ x 7’ x 36” 2.13m x 2.13m x 0.91m
Jet Count
41
Lighting System (interior)
Raio® multi-color points of light (27)
Exterior multi-color lighting with timer
Water Care System
FreshWater® Salt System Ready
Vinyl Cover Colors
Caramel
Chestnut
Slate
Jet Pump 1
Wavemaster® 8200
Two-speed
2.0 HP Continuous Duty
4.0 HP Breakdown Torque
Circulation Pump
SilentFlo 5000® for quiet continuous filtration
Control System
IQ 2020® with LCD control panel
230v/50amp, 60Hz
Includes G.F.C.I. protected sub-panel
Cover Lifters (Optional)
CoverCradle II®, CoverCradle®, Lift ‘n Glide®, UpRite®
Energy Efficiency
FiberCor® insulation; Certified to the APSP 14 National Standard and the California Energy Commission (CEC) in accordance with California law
Water Capacity
360 Gallons/1,365 Liters
Weight
845 lbs./385 kg dry
5,070 lbs./2,300 kg filled*
Heater
No-Fault®, 4000w/230v
Entertainment systems (optional)
Wireless Entertainment
Water Features
Vidro® backlit ribbon waterfall
Jet Pump 2
Wavemaster® 8000
One-speed
2.0 HP Continuous Duty
4.0 HP Breakdown Torque
Effective Filtration Area
100 sq. ft., top-loading filters
Steps (Optional)
Everwood®
Polymer
Vinyl Cover
3.5" to 2.5" tapered
2 lb. density foam core with hinge seal
Hot Tub Jets
1 XL Dual Rotary Jet
3 XL Single Rotary Jets
1 XL Directional Jet
4 Standard Directional Jets
4 Rotary Precision® Jets
28 Directional Precision® Jets

SOOTHING JETS AND STYLE

With seating for six, the Flair offers great versatility with both a row of open seats and a lounge. There’s generous space for your feet, and jets in the footwell and the lounge help give you a truly relaxing experience.

Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider

(Actual colors and product may differ from on screen representation. Please see your local dealer to verify.)

Cabinet

Shell

PRODUCT SPECS

Seating Capacity
6 Adults
Dimensions
7’ x 7’ x 36” 2.13m x 2.13m x .91m
Jet Count
43
Lighting System (interior)
Raio® multi-color points of light (32)
Exterior multi-color lighting with timer
Water Care System
FreshWater® Salt System Ready
Vinyl Cover Colors
Caramel
Chestnut
Slate
Jet Pump 1
Wavemaster® 8200
Two-speed
2.0 HP Continuous Duty
4.0 HP Breakdown Torque
Circulation Pump
SilentFlo 5000® for quiet continuous filtration
Control System
IQ 2020® with LCD control panel
230v/50amp, 60Hz
Includes G.F.C.I. protected sub-panel
Cover Lifters (Optional)
CoverCradle II®, CoverCradle®, Lift ‘n Glide®, UpRite®
Energy Efficiency
FiberCor® insulation; Certified to the APSP 14 National Standard and the California Energy Commission (CEC) in accordance with California law
Water Capacity
335 gallons/1,270 liters
Weight
875 lbs./400 kg dry
4,720 lbs./2,140 kg filled*
Heater
No-Fault®, 4000w/230v
Entertainment systems (optional)
Wireless Entertainment
Water Features
Vidro® backlit ribbon waterfall
Jet Pump 2
Wavemaster® 8000
One-speed
2.0 HP Continuous Duty
4.0 HP Breakdown Torque
Effective Filtration Area
100 sq. ft., top loading filters
Steps (Optional)
Everwood®
Polymer
Vinyl Cover
3.5" to 2.5" tapered
2 lb. density foam core with hinge seal
Hot Tub Jets
1 XL Dual Rotary Jet
2 XL Single Rotary Jets
1 XL Directional Jet
6 Standard Dual Rotary Jets
2 Standard Directional Jets
31 Directional Precision® Jets

SMALL STATURE. BIG POSSIBILITIES

Ideal for tighter spaces, the Beam has a smaller footprint but still provides spacious seating for four people. Each corner seat features a different hydrotherapy option and the large footwell is an added bonus in this spa’s roomy interior.

Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider Model Slider

(Actual colors and product may differ from on screen representation. Please see your local dealer to verify.)

Cabinet

Shell

PRODUCT SPECS

Seating Capacity
4 Adults
Dimensions
6’ 8” x 6’ 8” x 33” 2.03m x 2.03m x 0.84m
Jet Count
19
Lighting System (interior)
Raio® multi-color points of light (30)
Exterior multi-color lighting with timer
Water Care System
FreshWater® Salt System Ready
Vinyl Cover Colors
Caramel
Chestnut
Slate
Jet Pump 1
Wavemaster® 9000
One-speed
2.5 HP Continuous Duty
5.2 HP Breakdown Torque
or Wavemaster® 7000
One-speed
1.65 HP Continuous Duty
3.5 HP Breakdown Torque
Circulation Pump
SilentFlo 5000® for quiet continuous filtration
Control System
IQ 2020® with LCD control panel
230v/50amp, 60Hz
Includes G.F.C.I. protected sub-panel
or 115v/20amp, 60Hz
Includes G.F.C.I. protected power cord
Cover Lifters (Optional)
CoverCradle II®, CoverCradle®, Lift ‘n Glide®, UpRite®
Energy Efficiency
FiberCor® insulation; Certified to the APSP 14 National Standard and the California Energy Commission (CEC) in accordance with California law
Water Capacity
310 gallons/1,175 liters
Weight
700 lbs./320 kg dry
3,860 lbs./1,750 kg filled*
Heater
No-Fault®, 6000w/230v or 1,500w/115v
Entertainment systems (optional)
Wireless Entertainment
Water Features
Vidro® backlit ribbon waterfall
Effective Filtration Area
100 sq. ft., top-loading filters
Steps (Optional)
Everwood®
Polymer
Vinyl Cover
3.5" to 2.5" tapered
2 lb. density foam core with hinge seal
Hot Tub Jets
1 XL Directional Jet
2 Standard Single Rotary Jets
2 Standard Directional Jets
14 Directional Precision® Jets
